High Air Pressure DC Blower Fan 8000RPM Speed With Impedance Protected Motor

Product Categories
Shenzhen Topfan Technology Development Co., Ltd.
Contact Now

High Air Pressure DC Blower Fan 8000RPM Speed With Impedance Protected Motor

  • 1
  • 2

Brand Name : MX / OEM / ODM

Model Number : MX9733GBH1

Certification : CE, ROHS

Place of Origin : Guangzhou , China

MOQ : 100pcs

Price : us$12.99/ pcs to us$15.99 / pcs, and negotiation

Payment Terms : T/T, Western Union, paypal

Supply Ability : 600,000pcs per month

Delivery Time : 5 - 12 working days after received your payment

Packaging Details : carton, other can be customized

Product name : DC fan, blower centrifugal, centrifugal fan, dc fan12V 24V, dc motor fan, dc blower fan, blower motor, blower motor fan, dc brushless fan, dc 97*97*33mm,small fan, high flow fan, motor fan, air cleaner fan, air filter

Rate Voltage : 12V / 24V dc

Speed : 8000RPM and other speed you wanted

Bearing type : ball bearing

Motor : Impedance Protected And Reverse Polarity Protected

Weight : 164g

Frame and impeller material : Plastic (94V - 0) , PBT

Contact Now

DC high speed 8000rpm and high air pressure blower fan 97 x 95 x 33mm





Size and Net weight: 97*95*33mm blower fan, 300g.

Function and range: FG, PWM, RD, IP55-IP68, Thermal Control, Auto-Restart

Operating Temperature: -10℃~70℃ (35%~85%RH)

Storage Temperature : -40℃~70℃ (35%~85%RH)


High Air Pressure DC Blower Fan 8000RPM Speed With Impedance Protected Motor




Basic description :
● Size-------------------------- 97mm x 97mm x 33mm
● Material------- -------------- Plastic ( 94V - 0 ) , PBT
● Voltage---------------------- 5V 12V 24V DC
● Bearing type---------------- Ball bearing
● Expected life---------------- Ball bearing 50000-70000hours
● Lead wire-------------------- 2wire / 3 wire / 4wire
●Operating Temperature--- -10℃ ~ +70℃
● Storage Temperature----- -40℃ ~ +70℃



Applications :

  • Air conditioner / air cleaner
  • Ventilation Equipment & System
  • Heating Equipment & System
  • Air Conditioner
  • Refrigeration equipment
  • MDBS ( Mobile Data Base Station )
  • Telecom power supply station
  • industrial production equipment
  • medical equipment
  • home appliances
  • and etc.


Company information



Shenzhen Topfan Technology Development Co ., Ltd is a medium - sized enterprise which integrates production , research , development and sales . It has 3000 flat plant factory and with professional design and production team , founded 1991. At present , the company has production development department , Q & C department , R & D department , the domestic sales department and overseas sales department .

 In order to protect the customer' s rights and interests , all the products were tested strictly and repeatedly before being put on the market . According to the customer' s different requirements , we can do the following tests of fan : wind tunnel test , vibration test , noise test , drop test , salt spray test , waterproof test , dust test , cycle test of high and low temperature , life testing , simulation test of high altitude low voltage, and passed CE ROHS UL EML SGS and etc.

WE FOCUS ON HIGH QUALITY AND GOOD SERVICE

Shenzhen Topfan Technology Development Co ., Ltd is a medium - sized enterprise which integrates production , research , development and sales . It has 3000 flat plant and professional design and production team . At present , the company has production development department , Q & C department , R & D department , the domestic sales department and overseas sales department .
In order to protect the customer ` s rights and interests , all the products were tested strictly and repeatedly before being put on the market . According to the customer ’ s different requirements , we can do the following tests of fan : wind tunnel test , vibration test , noise test , drop test , salt spray test , waterproof test , dust test , cycle test of high and low temperature , life testing , simulation test of high altitude low voltage, and ten items tested ROHS .
