200 × 200 × 60mm AC Brushless Fan Motor , Equipment Exhaust Fan, Radiator Fan
Applications:
200 × 200 × 60mm AC Equipment Cooling Fan products are utilized by all type of machines which required heat reduction systems, such as computer information technology, network communications, as well as industrial production equipment, medical equipment, home appliances, etc.
Description:
- 200 × 200 × 60mm AC axial flow cooling fan.
- Waterproof, brushless ac motor fan, air-conditioner fan, LCD display fan, BBQ machine fan, server cabinet fan.
- Stable quality, big airflow, low noise.
- Both ball and sleeve bearing choose, copper wire.
- Motor protection: Impedance protect.
- Wire type: -AT Terminal / -AW Wires
- Working temperature:
- Ball bearing: -30°C~75°C
- Sleeve bearing: -10°C~70°C
- Protection level: IP44
- Net weight: 1600g
General Specification:
| Model | Bearing Type | Rated Voltage | Freq. | Current Amp | Input Power | Speed | Max Air Flow | Max Static Pressure | Noise Level | Weight |
| Part No. | S B Y | VDC | Hz | Amp | Watt | RPM | CFM | m3/min | Inch-H2O | dB-A | g |
| MX20060ABH11 | B | 110/120 | 50/60 | 0.4 | 60 | 2500/2800 | 420/490 | 13.0/14.9 | 0.6/0.72 | 60/65 | 1600 |
| MX20060ABH22 | B | 220/240 | 50/60 | 0.3 | 60 | 2500/2800 | 420/490 | 13.0/14.9 | 0.6/0.72 | 60/65 | 1600 |
Electrical Specification:
| Item | Specification/Condition |
| 01 | Dielectric Strength | 1800V/0.5mA/3s |
| 02 | Insulation Resistance | N/A |
| 03 | Temperature Test of Run | △t=<70℃ (Rated Voltage) |
| 04 | Locked Rotor Protection | △t=<130℃ (Rated Voltage) |
Safety Approvals:
| Safety Approvals | File No | Safety Approvals | File No |
| UL | N/A | RoHS-TUV | N/A |
| CUL | N/A | CCC | N/A |
| TUV | N/A | CE | N/A |
| TUV-GS | N/A | C-Tick | N/A |
Environmental Specification:
| Item | Specification/Condition |
| 01 | Operating Temp. Range | Temperature:-20℃~75℃
Humidity:20%~85%RH |
| 02 | Storage Temperature | Temperature:-30℃~140℃
Humidity:20%~95%RH |
| 03 | Life | 50000H |
Main Materials/Parts Specification:
| (Item | Specification |
| 01 | Blade | (PBT) PBT+15%GF |
| 02 | Frame | Aluminum ADC-12,Painted Black |
| 03 | Stator& Rotor | Silicon stee |
| 04 | Magnet Wires | Copper 2 UEW |
| 05 | Bobbin | PA-66 UL 94 V-0 |
Dimension:
Fan Performance Curve :
Speed Test:
Package:
About Our Company
1. As a professional manufacturer, we specialize in Brushless DC&AC cooling fans and CPU coolers for over 10 years.
2. Our products are extensively applied to all kinds of refrigeration equipments, air conditioner, cooling and ventilation instruments.
3. Customized design is available.
4. OEM &ODM service are welcome.
5.Factory qualification with CE,UL,ROHS,FCC,TUV.
How to Select a right cooling fan?
A: Where are you used? Application for what?
B: What's size limitation do you have?
C: What's voltage do you require (5V DC,12/24V DC, 85V-125V ,190V-250V)?
D: What's power or CFM airflow required?
It will help us to give you good idea to quote
